- Size: 1
- Place of Origin: SHAN DONG
- Brand Name: SINOTRUK
- Model Number: QY20A
- Weight: 1.000 kg
QY20A MAIN TECHNICAL SPECIFICATIONS | |||
ITEM | UNIT | DATA | |
WORKING PERFORMANCE SPECIFICATIONS
| Max rated lifting capacity | t | 20 |
Max lifting moment with min boom length | kN.m | 833 | |
Max lifting moment with max boom length | kN.m | 458 | |
Boom max lifting height | m | 31.7 | |
Jib max lifting height | m | 39.23 | |
MASS SPECIFICATIONS | Gross weight | kg | 26600 |
Front axle load | kg | 7000 | |
Rear axle load | kg | 19600 | |
WORKING SPEED | Single line max speed | m/min | 130 |
Lifting boom extending time | s | 70 | |
Lifting boom elevating time | s | 50 | |
Slewing speed | r/min | ≤2 | |
TRAVELLING SPECIFICATIONS | Max travelling speed | km/h | 75 |
Max gradeability | (%) | 28 | |
Min turning radius | m | 11 | |
Min clearance | mm | 325 | |
Approach angle | ° | 16 | |
Aagle of departure | ° | 12 | |
DIMENSION SPECIFICATIONS | Overall dimensions(L×W×H) | mm | 12360×2495×3580 |
Outrigger longitudinal span | mm | 4900 | |
Outrigger Transversal Span | mm | 5720 | |
Boom length | m | 10.1-31.1 | |
Jib length | m | 8 | |
CHASSIS | Type |
| TAZ5273J |
Diesel model |
| WD615.90 | |
Max power of engine | kw/rpm | 162/2200 | |
Max torque of engine | N·m/rpm | 900/1100-1600 | |
