- Size: 62M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ
- Weight: 9000.000 kg
Model ZZ5504N3640AJ Dimension 8060x3000x3425mm Dimension of box 5400x2800x1500mm(rectangular carrier) Wheel base 3600mm 1400mm Front/rear overhang 1500/1560mm Front/rear track 2400/2200mm Min. Ground clearance 305mm Dead weight 15560kg G.V.W 50000kg Axle loading capacity 9650/40350kg Cabin HOVA CABIN, Dual hydraulic locks,hydraulically 52°tilting to the front Engine: Model WD 615.69 Power 247kw/2200rpm Max. torque 1350Nm/1100~1600rpm Air intake Three air filtering, whirlwind pre-filtering, oil bath and air filtering Clutch FG420J Spiral spring Transmission: HW18709 12.68 8.46 6.26 4.64 3.38 2.50 1.85 1.37 1.00 R11.62 Drive axle Strengthened wide steel two-grade reducing and double tire axle Front axle Strengthened wide welded box stiff front shaft Tire 14.00-20-20PR or 14.00R20 Service brake Dual circle brake Park brake Spring energy air cut brake on front shaft and rear axle Electric system Single line 24V negative grounded Fuel tanker 400L
- Size: 62M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ
- Weight: 9000.000 kg
Model ZZ5504N3640AJ Dimension 8060x3000x3425mm Dimension of box 5400x2800x1500mm(rectangular carrier) Wheel base 3600mm 1400mm Front/rear overhang 1500/1560mm Front/rear track 2400/2200mm Min. Ground clearance 305mm Dead weight 15560kg G.V.W 50000kg Axle loading capacity 9650/40350kg Cabin HOVA CABIN, Dual hydraulic locks,hydraulically 52°tilting to the front Engine: Model WD 615.69 Power 247kw/2200rpm Max. torque 1350Nm/1100~1600rpm Air intake Three air filtering, whirlwind pre-filtering, oil bath and air filtering Clutch FG420J Spiral spring Transmission: HW18709 12.68 8.46 6.26 4.64 3.38 2.50 1.85 1.37 1.00 R11.62 Drive axle Strengthened wide steel two-grade reducing and double tire axle Front axle Strengthened wide welded box stiff front shaft Tire 14.00-20-20PR or 14.00R20 Service brake Dual circle brake Park brake Spring energy air cut brake on front shaft and rear axle Electric system Single line 24V negative grounded Fuel tanker 400L
