Engine

Make: SINOTRUK
Engine model: WD615.47, Euro II                  emission standard
4 stroke direct injection diesel                  engine
6 cylinder in-line with water cooling,                  turbo-charging & intercooling
Maximum output:                  371hp(273Kw)at 2200 rpm according to DIN
Maximum                  torque: 1350Nm at 1100~1600 rpm
Bore: 126mm;                   Stroke: 130mm; Displacement: 9.726L;  Compression                  ratio:17:1
Specific fuel consumption: 195g/kWh;                   Engine oil filling quantity: 23L
Cooling system                  filling quantity (long-term filling): 40L
                 Thermostat opening temperature: 80oC
Twin cylinder                  air compressor

Clutch

Single- plate dry coil-spring clutch, diameter 430mm,                  hydraulically operating with air assistance

Transmission

Transmission, model HW19710, synchromesh, 10 forward                  and 2 reverse
Ratio:                  14.28;10.62;7.87;5.88;4.38;3.27;2.43;1.8;1.34;1

Propeller Shaft

Double universal joint propeller shaft with                  gear-shaped coupling flange

Front Axle

HF9

Rear Axles

AC16

Chassis

Frame: U-profile parallel ladder type with section of                  300×80×8 mm, all cold riveted cross members and                  reinforced subframe
Front suspension: 10                  semi-elliptic leaf springs with hydraulic telescopic                  double-action shock absorbers and stabilizer
Rear                  suspension: 12 semi-elliptic leaf springs with bogie                  spring and stabilizer
With one spare wheel
                 Fuel tank: with 300 L fuel tank with locking fuel cap

Steering

ZF8118 , hydraulic steering with power assistance

Brakes

Service brake: dual circuit compressed air brake
                 Parking Brake(emergency brake): spring energy,                  compressed air operating on rear wheels
Auxiliary                  brake: engine exhaust brake

Wheel & Types

12.00R20

Driver’s cab

Flat roof top,all-metal,hydraulic tilting cab,one-side                  cab

Electrics

Operating voltage:24V, negative grounded;  Starter:                  24V, 5.4KW
Alternator: 3-phrase, 28V, 1500W;                   Batteries: 2×12, 180Ah
Cigar-lighter, horn,                  headlamp, fog light, brake lights, indicators and                  reverse lamp

Dimensions in mm

Wheel base
Front wheel track
Rear wheel                  track
Front overhang
Rear overhang
                 Approach angle(o)
Departure angle(o)
Overall                  Dimension
Cargo body size

3800 1400
2441
2420
1500
1870
                 29
23
8545×2496×3340(mm)
5600×2300×1500                  (mm)

Weight in kg

Permissible loading capacity on chassis
Dead                  weight
Gross vehicle weight
Front axle loading                  capacity
Rear axle loading capacity

30000
13000
30000
9000
16000×2

Performance

Maximum driving speed(km/h)
Maximum grade ability                  (%)
Minimum ground clearance(mm)
Minimum                  turning circle(m)

78
42
314
17
