SINOTRUK Heavy Tractor 180ton

SINOTRUK Heavy Tractor 180ton

  • Min.Order Quantity: 1 Set
  • Supply Ability: 9999 Sets per Month
  • Port: Any China Port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:1994-12-29
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  Jinan, China
  • Brand Name:  SINOTRUK
  • Model Number:  TAZ4922

TAZ4922 Heavy Tractor

Main parameters and configuration

Model

TAZ4922

Drive type

6×6

Mass parameters

Total mass/Kerb masskg

92000/34000

Rated vertical load capacityT

58

traction capacityT

180

Full-load bearing on various axlekg

Front axle

22000

Intermediate axle

35000

Rear axle

35000





Dimension parameters

Overall dimensionsmm

14057×3500×4150(full-loaded)

Wheel trackmm

2718/2718

Wheel basemm

7800 2030

fifth wheel heightmm

2667

Minimum ground clearancemm

430

Front/Rear turning radiusmm

6616/3042



Operation parameters

Maximum gradeability%

45

Minimum turning radiusm

25

Maximum speed (no-load/full-loaded) km/h

80/30

Applicable

-20~60

Engine

Model

QSX15-C600Euro Ⅱ)

Max.torqueN.m/r/min

2779/1400

Power/rotate speedKW/r/min

600HP447kw/1900

Gearbox

Model

Allison M6620AR

Velocity ratio

4.002.682.011.351.000.67R: -5.15

Saddle

model

single pendulum

Longitudinal oscillating range°

±12

king pin

3 1/2

Winch

Model

HP100B

Max. tensionT

45

Cab

CNHTC cab

Tires

29.5R25(equipped with inflation/deflation system


  • Place of Origin:  Jinan, China
  • Brand Name:  SINOTRUK
  • Model Number:  TAZ4922

TAZ4922 Heavy Tractor

Main parameters and configuration

Model

TAZ4922

Drive type

6×6

Mass parameters

Total mass/Kerb masskg

92000/34000

Rated vertical load capacityT

58

traction capacityT

180

Full-load bearing on various axlekg

Front axle

22000

Intermediate axle

35000

Rear axle

35000





Dimension parameters

Overall dimensionsmm

14057×3500×4150(full-loaded)

Wheel trackmm

2718/2718

Wheel basemm

7800 2030

fifth wheel heightmm

2667

Minimum ground clearancemm

430

Front/Rear turning radiusmm

6616/3042



Operation parameters

Maximum gradeability%

45

Minimum turning radiusm

25

Maximum speed (no-load/full-loaded) km/h

80/30

Applicable

-20~60

Engine

Model

QSX15-C600Euro Ⅱ)

Max.torqueN.m/r/min

2779/1400

Power/rotate speedKW/r/min

600HP447kw/1900

Gearbox

Model

Allison M6620AR

Velocity ratio

4.002.682.011.351.000.67R: -5.15

Saddle

model

single pendulum

Longitudinal oscillating range°

±12

king pin

3 1/2

Winch

Model

HP100B

Max. tensionT

45

Cab

CNHTC cab

Tires

29.5R25(equipped with inflation/deflation system
