Technical Specifications

Main Notes

Water tank: 4000L

CAFS Foam tank: 500L
CAFS Pump flow: 3000 lpm (800 USgpm)
With Class A Foam
FEATURES
All-aluminum body and stainless steel tank.
Light weight, and will never rust.
Stainless steel pipelines
Centralized control panel that makes operation and
use extremely easy.
Variety hose connectors.
With manhole at the top of the water pump room.
With US made Automatic High efficient CAFS foam
extinguishing system.
High flow rate.
Remote control monitor.
Overall Measurement (L*W*H) 8600*2500*3450 mm
Chassis Brand SINOTRUK HOWO ZZ1167M4617C
Driving form 4*2
Wheel Base 4600mm
Curb Mass 12000 kg
Outrigger Transversal Span
Water T ank Capacity 4000L
Foam T ank Capacity 500L
Engine Power 196kw
Max Vehicle Speed ≥90km/h
Min Turning Diameter 21.8m
Class A Foam System HALE PTO-CAFS120 (US made)
Fire Pump Model HALE 50FBU
Monitor Model AKRON 3425 2499(US made)
Water Pump Flow 3000 lpm (800 USgpm)
Water Pump Pressure 1 MPa
Monitor Flow Rate 2400 lpm (640 USgpm)
Monitor Range 60m
Water Pumper Inlet Diameter 1*125 mm
Water Pumper Outlet Diameter 4*80 mm(2 for each side)
Water outlet at cage
Water T ank Inlet Diameter 2*65 mm(1 for each side)
Foam suction inlet
Proportioning Mixer HALE Foamlogix3.3
Foam proportion 0.1-3% (adjustable)
Class A foam system pressure 0.85 MPa
Air compressor flow 3.5 MPa (Should be Cubic Meters, please reconfirm this point.)
Class A Foam Pump Flow 12.5 cubic m/min, [as per the discussion with our senior
engineer, this point should be reconsidered, this is not proper.]
Class A Foam Outlet 2*65 (1 for each side)
Class A Foam Flow
8 (dry foam)
16 (wet foam)
Monitor Swivel Angle
Turret (optional)
Monitor Pitch Angle
Driver's Cab 6 persons
