- Place of Origin: Jinan, China
- Brand Name: SINOTRUK
- Model Number: TAZ4653
TAZ4653 Heavy Tractor
Main parameters and configurations | ||||
Model | TAZ4653 | |||
Drive type | 6×6 | |||
Mass parameters | Total mass/Kerb mass（kg） | 65000/24000 | ||
Rated vertical load capacity（kg） | 45000 | |||
traction capacity（kg） | 130000 | |||
Full-load bearing on various axle（kg） | Front axle | 13000 | ||
Intermediate axle | 26000 | |||
Rear axle | 26000 | |||
Dimension parameters | Overall dimensions（mm） | 9470×3000×4020(full-loaded) | ||
Wheel track（mm） | 2540/2060 | |||
Wheel base（mm） | 4000 1650 | |||
fifth wheel height（mm） | 2008 double pendulum | |||
1908 single pendulum | ||||
Minimum ground clearance（mm） | 412 | |||
Front/Rear turning radius（mm） | 2140/2246 | |||
Operation parameters | Max gradeability（%） | 30 | ||
Minimum turning radius（m） | 11.5 | |||
Maximum speed (no-load/full-loaded) （km/h） | 80/30 | |||
Applicable | -20℃~60℃ | |||
Engine | Model | ISXe525 30（Euro Ⅲ） | ||
Max.torque（N.m/r/min） | 2237/1200 | |||
Power/rotatespeed（KW/r/min） | 525HP（391kw）/1800 | |||
Model | Allison 4700P | |||
Velocity ratio | 7.63，3.51，1.91，1.43，1.00，0.74，R: -4.80 | |||
Saddle | model | single pendulum | double pendulum | |
Horizontal/Longitudinal oscillating range（°） | -/±12 | ±10/±10 | ||
king pin | 3 1/2“ | |||
Winch | Model | HP100B | ||
Max. tension（T） | 45 | |||
Cab | CNHTC cab | |||
Tires | 16.00R25(equipped with inflation/deflation system） | |||
