SINOTRUK 6X6 Heavy Tractor TAZ4413

SINOTRUK 6X6 Heavy Tractor TAZ4413

  • Min.Order Quantity: 1 Set
  • Supply Ability: 9999 Sets per Month
  • Port: Any China Port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:1994-12-29
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  Jinan, China
  • Brand Name:  SINOTRUK
  • Model Number:  TAZ4413

TAZ4413 Heavy Tractor

Main parameters and configurations

Model

TAZ4413

Drive type

6×6

Mass parameters

Total mass/Kerb masskg

41000/13000

Rated vertical load capacity(kg)

28000

traction capacity(kg)

100000

Full-load bearing on various axlekg

Front axle

9000

Intermediate axle

16000

Rear axle

16000





Dimension parameters

Overall dimensionsmm

7720×2500×3266(full-loaded)

Wheel trackmm

1884/1873

Wheel basemm

3600 1470

fifth wheel heightmm

1716

Minimum ground clearancemm

412

Front/Rear turning radiusmm

1980/2300



Operation parameters

Maximum gradeability%

27.7

Minimum turning radiusm

10.5

Maximum speed (no-load/full-loaded) km/h

76.5

Applicable

-20~60

Engine

Model

 MC11.43-30

Max.torqueN.m/r/min

2100/10001400

Power/rotate speedKW/r/min

 430HP316kw/1900

Gearbox

Model

Allison 4500

Velocity ratio

4.702.211.531.00         0.760.67R: -5.55

Saddle

model

double pendulum

Rated vertical load capacityT

36

Horizontal/Longitudinal oscillating range°

±7/±15

king pin

3 1/2

Winch

Model

HP100B

Max. tensionT

45

Cab

CNHTC cab

Tires

                             12.00R24
