- Size: 1
- Place of Origin: SHAN DONG
- Brand Name: SINOTRUK
- Model Number: ZZ3167M3811
- Weight: 1.000 kg
Model | QDZ5160ZYSA |
Chassis Model | ZZ3167M3811 |
Overall Dimensions(L×W×H)(mm) | 8065x2500x3150 |
Pressure of Hydraulic System(MPa) | 20 |
Kerb Mass(kg) | 9840 |
Loading Mass(kg) | 6030 |
Gross Vehicle Weight(kg) | 16000 |
Max. Speed (kg/h) | 90 |
Engine Model | WD615.87(EuroⅡ)290HP |
Engine Output (KW/r/min) | 193/2300 |
Body Volume ( m3) | 12 |
Filler Volume ( m3) | 2.0 |
Cycle Time of Filling (s) | ≤25 |
Lifting Time of Filler(s) | 8-10 |
Time of Discharging(s) | ≤40 |
Front / Rear Sewage Tank volume(L) | 250 150 |
Max.Compression Force(kg) | >25000 |
- Size: 1
- Place of Origin: SHAN DONG
- Brand Name: SINOTRUK
- Model Number: ZZ3167M3811
- Weight: 1.000 kg
Model | QDZ5160ZYSA |
Chassis Model | ZZ3167M3811 |
Overall Dimensions(L×W×H)(mm) | 8065x2500x3150 |
Pressure of Hydraulic System(MPa) | 20 |
Kerb Mass(kg) | 9840 |
Loading Mass(kg) | 6030 |
Gross Vehicle Weight(kg) | 16000 |
Max. Speed (kg/h) | 90 |
Engine Model | WD615.87(EuroⅡ)290HP |
Engine Output (KW/r/min) | 193/2300 |
Body Volume ( m3) | 12 |
Filler Volume ( m3) | 2.0 |
Cycle Time of Filling (s) | ≤25 |
Lifting Time of Filler(s) | 8-10 |
Time of Discharging(s) | ≤40 |
Front / Rear Sewage Tank volume(L) | 250 150 |
Max.Compression Force(kg) | >25000 |
