- Size: 1
- Place of Origin: SHAN DONG
- Brand Name: SINOTRUK
- Model Number: HS12G1-00
- Weight: 1.000 kg
Type | Max capacity | S-cam 、 Brake | Track | brake chamber distance | axle beam | Bearing | ||||
Φ × width | L2 | L3 | = | |||||||
Kg | mm | mm | mm | mm | ||||||
HS12A1-00 | 12,000 | S 420 ×180 | 1840 | 425 | 150 | 33213 /33118 | ||||
HS12A2-00 | 12,000 | S 420 ×180 | 1840 | 425 | 150 | 33213 /33118 | ||||
HS12C1-00 | 12,000 | S 420 ×180 | 2040 | 622 | Φ127 | 33213 /33118 | ||||
HS12G1-00 | 12,000 | S 420 ×180 | 1840 | 422 | 150 | 33213 /33118 | ||||
wheel fixing | Total Length | Recommend wheel | Weight |
| ||||||
stub | P.C.D | H | L1 |
| ||||||
| mm | mm | mm |
| kg |
| ||||
10*M22*1.5 ISO | 335 | 281 | ≈2156 | 7.50v-20 | ≈376 kgs |
| ||||
10*M22*1.5 ISO | 335 | 281 | ≈2156 | 7.50v-20 | ≈376 kgs |
| ||||
10*M22*1.5 ISO | 335 | 281 | ≈2356 | 7.50v-20 | ≈384kgs |
| ||||
10*M22*1.5 ISO | 335 | 281 | ≈2156 | 7.50v-20 | ≈365 kgs |
| ||||
