- Size: 75M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ3317M2861
- Weight: 16000.000 kg
1, Howo tippers: Howo 4x2 tipper; Howo 6x4 tipper; Howo 8x4tipper.
2, Howo concrete mixers: Howo 6x4 mixer; Howo 8x4 mixer. including7m3,8m3,9m3,10m3,11m3 and 12m3,
3,Howo tracotrs: Howo 4x2 tractor; Howo 6x4 tractor
Engine power for the above heavy duty trucks is 266HP,290HP, 336HP,371HPand 420HP.
We markets Howo trucks in more than 50 countries and districts all over the world, includes Russia, Ukraine, Iran, Indonesia,Vietnam, Saudi Arabia, Algeria, Nigeria, Sudan, Angora,Turkey, Brazil, Peru,Cuba, etc.
- Size: 75M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ3317M2861
- Weight: 16000.000 kg
Representative vehicle models | ZZ3257N3847A | |
CAB | Model | HW76 |
Type | 1 Bed | |
Engine | Model | 371 horsepower |
Rated power kW/rpm | 273KW | |
Displacement L | 9.726 | |
Type | In-line, six cylinders, supercharging intercooling, central supercharger, E-control CRDI | |
Transmission | China National heavy duty truck HW Series HW19710 | |
Front axle | HF9 | |
Rear drive axle | AC16 | |
Steering system | ZF8098 | |
Tire | 1200R20/1200R22.5/1200-20 | |
Curb weight kg | 12150 | |
Total mass kg | 25000 | |
Trailer mass kg | 40000 | |
Overall dimensions (l x w x h) mm | 8500×2496×3317 | |
Wheel base mm | 3800 1350,3750 1400 | |
Front suspension / Rear suspension mm | 1500/725/ 1500/675 | |
Track width (front / After) mm | 2022/1830 | |
Approach angle / Angle of departure ° | 19/67 | |
Maximum speed km/h | 75 | |
