- Size: 57M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ4257V3247N1B
- Weight: 9000.000 kg
SINOTRUK is the biggest and also the earliest heavy duty truck manufacture in China, specialized in the researching, developing and manufacturing of heavy trucks and related key parts. The products include truck chassis with GCW over 14 tons as well as tractor trucks with hauling capacity over 12 tons, tipper trucks, special trucks etc.
The truck products range from tractor trucks, cargo trucks, crane mounted trucks, garbage trucks, water trucks etc. And the trailer products range from flatbed trailers, tipper trailers, tank trailers, concrete mixer trailers etc.
- Size: 57M3
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ4257V3247N1B
- Weight: 9000.000 kg
General information | |||
Driving Type: | 6x4 | Model Number: | ZZ4257N3247N1B |
Whole Dimension: | 6985*2550*3850 mm | Wheel base: | 3225 1350mm |
Loading weight: | 30-40 ton | Max speed: | 102km/h |
Engine | |||
Engine No: | WD615.47 | Cylinder No | 6 |
Fuel type: | Diesel | Emission: | 9.726L |
Emission standard: | Euro II | Horse power: | 371hp |
Max output rate: | 273kw | Torque: | 1500n.m |
Max twist speed: | 1100-1600r/min | Rated rotate speed | 2200rpm |
Gearbox | |||
Gearbox No: | HW19710 | Transmission Type: | Manual |
Forward: | 10 speed | Reverse: | 2 speed |
Chassis and tire | |||
Front axle: | HF9 | Front axle loading: | 9000kg |
Rear axle: | HC16 x2 | Rear axle loading: | 16000kg x2 |
Tires | 12.00-20/12.00R20 | Tire quantity: | 11, with one spare tire |
Fifth wheel | 2” (50#) or3.5”(90#) | ||
Note: 266hp, 336hp, 371hp, 420hp engine power is optional. | |||
